CuringPen
Eighteeth
A pen-style LED curing light with four LEDs — three blue and one violet — for curing restorative materials and violet-light caries detection. The emission spectrum has two peaks — 470 nm from the blue LEDs and 410 nm from the violet LED — within 385–515 nm. Three intensities — 1000, 1500 and 2300 mW/cm² — plus Ramp and Pulse modes match the exposure to the material and case, and a head that rotates 360° eases access to every area of the mouth. The manufacturer states that a control chip keeps light output consistent and that a full charge delivers more than 1200 exposures of 3 seconds at 2300 mW/cm².
- Supply, installation and staff training by JK Dent
- Full warranty
- Service and maintenance — response within 24 hours
Key features
- Four LEDs: three blue and one violet, peaking at 470 and 410 nm
- Three curing intensities: 1000, 1500 and 2300 mW/cm²
- Ramp and Pulse modes — gradual intensity rise or intermittent exposure
- Violet-light caries detection mode at 600 mW/cm²
- Head rotates 360° — easy access to every area of the mouth
- Digital display of program, intensity, time and battery level
Technical specifications
- Type
- pen-style LED curing light
- Light source
- 4 LEDs — 3 blue, 1 violet, 10 W
- Wavelength
- 385–515 nm (peaks at 410 and 470 nm)
- Light intensity
- 1000 · 1500 · 2300 mW/cm²
- Detect mode
- 600 mW/cm²
- Ramp mode
- rises to 1000 mW/cm² over the first 5 s
- Pulse mode
- 0.8 s on, 0.2 s off, at 1000 mW/cm²
- Head
- rotates 360°, 13 mm diameter, 9.3 mm output lens
- Dimensions
- 24 × 21 × 230 mm
- Net weight
- 109 g
- Per charge
- more than 1200 exposures of 3 s at 2300 mW/cm²
Data as published by the manufacturer. Details vary by configuration — talk to us.
